vl::Object Class Reference

The base class for all the reference counted objects. More...

#include <Object.hpp>

Inheritance diagram for vl::Object:

List of all members.

Public Member Functions
	Object ()
	Constructor.
	Object (const Object &other)
	Copy constructor: copies the name, ref count mutex and user data.
Object &	operator= (const Object &other)
	Copy operator: copies the object's name, ref count mutex and user data.
const std::string &	objectName () const
	The name of the object, by default set to the object's class name.
void	setObjectName (const char *name)
	The name of the object, by default set to the object's class name in debug builds.
void	setRefCountMutex (IMutex *mutex)
	The mutex used to protect the reference counting of an Object across multiple threads.
IMutex *	refCountMutex ()
	The mutex used to protect the reference counting of an Object across multiple threads.
const IMutex *	refCountMutex () const
	The mutex used to protect the reference counting of an Object across multiple threads.
int	referenceCount () const
	Returns the number of references of an object.
void	incReference () const
	Increments the reference count of an object.
void	decReference ()
	Decrements the reference count of an object and deletes it if both automaticDelete() is true the count reaches 0.
void	setAutomaticDelete (bool autodel_on)
	If set to true the Object is deleted when its reference count reaches 0.
bool	automaticDelete () const
	If set to true the Object is deleted when its reference count reaches 0.
template<class T >
T *	as ()
	Casts an Object to the specified class.
template<class T >
const T *	as () const
	Casts an Object to the specified class.
Protected Member Functions
virtual	~Object ()
Protected Attributes
std::string	mObjectName
IMutex *	mRefCountMutex
int	mReferenceCount
bool	mAutomaticDelete

---

Detailed Description

The base class for all the reference counted objects.

See also vl::ref.

Definition at line 55 of file Object.hpp.

---

Constructor & Destructor Documentation

vl::Object::Object

(

)

[inline]

Constructor.

Definition at line 61 of file Object.hpp.

References NULL, and VL_DEBUG_SET_OBJECT_NAME.

vl::Object::Object

(

const Object &

other

)

[inline]

Copy constructor: copies the name, ref count mutex and user data.

Definition at line 78 of file Object.hpp.

References mObjectName, and mRefCountMutex.

Object::~Object

(

)

[protected, virtual]

Definition at line 45 of file Object.cpp.

References automaticDelete(), vl::Log::bug(), mObjectName, and mReferenceCount.

---

Member Function Documentation

Object& vl::Object::operator=

(

const Object &

other

)

[inline]

Copy operator: copies the object's name, ref count mutex and user data.

Definition at line 98 of file Object.hpp.

References mObjectName, and mRefCountMutex.

Referenced by vl::VLTTokenizer::getToken().

const std::string& vl::Object::objectName

(

)

const [inline]

The name of the object, by default set to the object's class name.

Definition at line 114 of file Object.hpp.

Referenced by vl::TextureSampler::apply(), vl::GLSLShader::compile(), vl::VLXClassWrapper_Actor::exportActor(), vl::VLXClassWrapper_Camera::exportCamera(), vl::VLXClassWrapper_DrawCall::exportDrawCallBase(), vl::VLXClassWrapper_Effect::exportEffect(), vl::VLXClassWrapper_GLSLProgram::exportGLSLProgram(), vl::VLXClassWrapper_Light::exportLight(), vl::VLXClassWrapper_Material::exportMaterial(), vl::VLXClassWrapper_Renderable::exportRenderable(), vl::VLXClassWrapper_ResourceDatabase::exportResourceDatabase(), vl::VLXClassWrapper_Shader::exportShader(), vl::VLXClassWrapper_Texture::exportTexture(), vl::VLXClassWrapper_Transform::exportTransform(), vl::VLXClassWrapper_VertexAttrib::exportVertexAttrib(), vl::VLXClassWrapper_Viewport::exportViewport(), vl::GLSLProgram::infoLog(), vl::MorphingCallback::init(), vl::GLSLProgram::linkProgram(), vl::DaeLoader::load(), vl::Image::print(), vl::GLSLProgram::programBinary(), and vl::GLSLProgram::useProgram().

void vl::Object::setObjectName

(

const char *

name

)

[inline]

The name of the object, by default set to the object's class name in debug builds.

Definition at line 117 of file Object.hpp.

Referenced by vl::Texture::createTexture(), vl::Image::Image(), vl::VLXClassWrapper_Actor::importActor(), vl::VLXClassWrapper_Camera::importCamera(), vl::VLXClassWrapper_DrawCall::importDrawCall(), vl::VLXClassWrapper_Effect::importEffect(), vl::VLXClassWrapper_GLSLProgram::importGLSLProgram(), vl::VLXClassWrapper_Light::importLight(), vl::VLXClassWrapper_Material::importMaterial(), vl::VLXClassWrapper_Renderable::importRenderable(), vl::VLXClassWrapper_ResourceDatabase::importResourceDatabase(), vl::VLXClassWrapper_Shader::importShader(), vl::VLXClassWrapper_Texture::importTexture(), vl::VLXClassWrapper_Transform::importTransform(), vl::VLXClassWrapper_VertexAttrib::importVertexAttrib(), vl::VLXClassWrapper_Viewport::importViewport(), vl::loadDDS(), and vl::GLSLShader::setSource().

void vl::Object::setRefCountMutex

(

IMutex *

mutex

)

[inline]

The mutex used to protect the reference counting of an Object across multiple threads.

Definition at line 120 of file Object.hpp.

IMutex* vl::Object::refCountMutex

(

)

[inline]

The mutex used to protect the reference counting of an Object across multiple threads.

Definition at line 123 of file Object.hpp.

const IMutex* vl::Object::refCountMutex

(

)

const [inline]

The mutex used to protect the reference counting of an Object across multiple threads.

Definition at line 126 of file Object.hpp.

int vl::Object::referenceCount

(

)

const [inline]

Returns the number of references of an object.

Definition at line 129 of file Object.hpp.

void vl::Object::incReference

(

)

const [inline]

Increments the reference count of an object.

Definition at line 135 of file Object.hpp.

void vl::Object::decReference

(

)

[inline]

Decrements the reference count of an object and deletes it if both automaticDelete() is true the count reaches 0.

Definition at line 149 of file Object.hpp.

References vl::IMutex::lock(), vl::IMutex::unlock(), and VL_CHECK.

void vl::Object::setAutomaticDelete

(

bool

autodel_on

)

[inline]

If set to true the Object is deleted when its reference count reaches 0.

Definition at line 169 of file Object.hpp.

Referenced by vl::ActorTreeAbstract::ActorTreeAbstract(), vl::DrawPixels::DrawPixels(), vl::Geometry::Geometry(), vl::MarchingCubes::MarchingCubes(), vlMFC::MDIWindow::MDIWindow(), vlMFC::MFCWindow::MFCWindow(), vlQt4::Qt4Widget::Qt4Widget(), vlQt5::Qt5Widget::Qt5Widget(), vl::SceneManagerVectorGraphics::SceneManagerVectorGraphics(), vl::VectorGraphics::VectorGraphics(), and vlWX::WXGLCanvas::WXGLCanvas().

bool vl::Object::automaticDelete

(

)

const [inline]

If set to true the Object is deleted when its reference count reaches 0.

Definition at line 172 of file Object.hpp.

Referenced by ~Object().

template<class T >

T* vl::Object::as

(

)

[inline]

Casts an Object to the specified class.

Definition at line 176 of file Object.hpp.

Referenced by vl::PolygonSimplifier::collapse(), vl::expandResourceDatabase(), vl::VLXClassWrapper_Array::export_ArrayT(), vl::VLXClassWrapper_ActorEventCallback::exportActorEventCallback(), vl::VLXClassWrapper_DrawCall::exportDrawCall(), vl::VLXClassWrapper_LODEvaluator::exportLODEvaluator(), vl::VLXClassWrapper_TextureSampler::exportVLX(), vl::VLXClassWrapper_TexParameter::exportVLX(), vl::VLXClassWrapper_Texture::exportVLX(), vl::VLXClassWrapper_ActorEventCallback::exportVLX(), vl::VLXClassWrapper_Material::exportVLX(), vl::VLXClassWrapper_Normal::exportVLX(), vl::VLXClassWrapper_SecondaryColor::exportVLX(), vl::VLXClassWrapper_Color::exportVLX(), vl::VLXClassWrapper_VertexAttrib::exportVLX(), vl::VLXClassWrapper_GLSLShader::exportVLX(), vl::VLXClassWrapper_GLSLProgram::exportVLX(), vl::VLXClassWrapper_ClipPlane::exportVLX(), vl::VLXClassWrapper_Light::exportVLX(), vl::VLXClassWrapper_Transform::exportVLX(), vl::VLXClassWrapper_Viewport::exportVLX(), vl::VLXClassWrapper_Camera::exportVLX(), vl::VLXClassWrapper_Actor::exportVLX(), vl::VLXClassWrapper_Effect::exportVLX(), vl::VLXClassWrapper_LODEvaluator::exportVLX(), vl::VLXClassWrapper_Shader::exportVLX(), vl::VLXClassWrapper_Uniform::exportVLX(), vl::VLXClassWrapper_ResourceDatabase::exportVLX(), vl::VLXClassWrapper_PatchParameter::exportVLX(), vl::VLXClassWrapper_DrawCall::exportVLX(), vl::VLXClassWrapper_VertexAttribInfo::exportVLX(), vl::VLXClassWrapper_Geometry::exportVLX(), vl::Geometry::flipNormals(), vl::VLXClassWrapper_ActorEventCallback::importActorEventCallback(), vl::VLXClassWrapper_DrawCall::importDrawCall(), vl::VLXClassWrapper_GLSLProgram::importGLSLProgram(), vl::VLXClassWrapper_LODEvaluator::importLODEvaluator(), vl::VLXClassWrapper_Transform::importTransform(), vl::Applet::initialize(), vl::DaeLoader::load(), vl::DepthSortCallback::onActorRenderStarted(), vl::VLXValue::setArray(), and vl::Geometry::sortVertices().

template<class T >

const T* vl::Object::as

(

)

const [inline]

Casts an Object to the specified class.

Definition at line 180 of file Object.hpp.

---

Member Data Documentation

std::string vl::Object::mObjectName [protected]

Definition at line 194 of file Object.hpp.

Referenced by vl::GLSLFragmentShader::GLSLFragmentShader(), vl::GLSLGeometryShader::GLSLGeometryShader(), vl::GLSLTessControlShader::GLSLTessControlShader(), vl::GLSLTessEvaluationShader::GLSLTessEvaluationShader(), vl::GLSLVertexShader::GLSLVertexShader(), Object(), operator=(), vl::Image::reset(), and ~Object().

IMutex* vl::Object::mRefCountMutex [protected]

Definition at line 196 of file Object.hpp.

Referenced by Object(), and operator=().

int vl::Object::mReferenceCount [mutable, protected]

Definition at line 197 of file Object.hpp.

Referenced by ~Object().

bool vl::Object::mAutomaticDelete [protected]

Definition at line 198 of file Object.hpp.

---

The documentation for this class was generated from the following files:

• X:/dropbox/visualizationlibrary/src/vlCore/Object.hpp
• X:/dropbox/visualizationlibrary/src/vlCore/Object.cpp
